PAGE 37
FIREBALL INSTALLATION & USER’S GUIDE - M22001-01A1
CHAPTER 2 - SETTING UP FIREBALL
Connecting Pioneer Changers
u Use an RS-232 cable (not supplied with FireBall) with connectors made
specically so that one end connector ts the pin conguration for FireBall and
the other end connector ts the pin conguration for your specic CD changer.
Refer to Appendix A for the pin congurations.
v Insert one end of the cable (the FireBall connector end) into an RS-232 COM
port on FireBall. There are 3 available COM ports.
w Insert the other end of the cable (the connector that ts the CD Changer) into the
RS-232 port on the CD Changer.
x To connect additional CD changers, repeat steps 1 through 3 using the other
COM ports.
y Connect audio from each CD Changer to FireBall. Connections using optical
cables to the digital ports will produce the highest quality audio.
z Make sure the changer is powered on.
2
Refer to Appendix A for cable pin-
out congurations.
2
When connecting digital audio
inputs to FireBall, make sure
Digital Audio 1 is from Changer
1, Digital Audio 2 is from
Changer 2, and Digital Audio 3 is
from Changer 3.
