PAGE 38
FIREBALL INSTALLATION & USER’S GUIDE - M22001-01A1
CHAPTER 2 - SETTING UP FIREBALL
Connecting Kenwood Changers
u Use the RS-232 cable which is supplied with the Kenwood changer
v Insert one end of the cable (the FireBall connector end) into an RS-232 COM
port on FireBall.
w Insert the other end of the cable (the connector that ts the Kenwood Changer)
into the RS-232 port on the rst Kenwood Changer.
x To connect additional Kenwood changers, connect a stereo 1/8" cable (not
included with FireBall) from changer 1 to changer 2, and from changer 2 to
changer 3 using the DAISY CHAIN CONTROL ports. FireBall will support up
to 3 Kenwood changers connected in this manor.
y Connect the coaxial digital output from the rst changer to the digital coaxial
input 1 on FireBall.
z If you have more than 1 Kenwood changer, you will need to daisy-chain the
digital coax audio from each changer into the st changer. Connect the coaxial
digital output of the second changer to the coaxial digital input on the rst
changer. Do the same for a third Kenwood changer, connecting it to the coaxial
digital input on the second changer.
