4 Wiring Diagram

4-1 Head

Left motor drive board assy

Position detecting sensor harness

Motor drive unit harness

Sensor relay harness

Right motor drive board assy

Position detecting sensor harness

VD-L assy

LED harness for

lighting eyeball

LED board assy for

lighting left

eyeball

LED board assy for

lighting right eyeball

VD-R assy

LED harness for

lighting eyeball
