101
CV Surname description range value
112 Time for twinkling effects Blinking frequency of the strobe effects.
Always a multiple of 0.065536 seconds. See. Section 12.5.4.
0 - 255 20
113 Power Fail Bypass Time, which bridges the decoder after a power interruption from the power pack. Unit:
multiple of 0.016384 seconds. See 6.12.2.
0 - 255 32
116 EMF measurement period (sampling rate) at
Vmin
Frequency of the EMF measurement in 0.1 milliseconds at speed level 1 50-200 50
117 EMF measurement period (sample) at
Vmax
Frequency of the EMF measurement in 0.1 milliseconds at speed level 255 50-200150
118 Length of the blanking interval of the back emf
voltage at VMin
Length of the measurement gap in 0.1 milliseconds at speed level 1 10-20150
119 Length of the blanking interval of the back emf
voltage at Vmax
Length of the measurement gap in 0.1 milliseconds at speed level 255 10 - 20 15
123 ABC Mode "slowly" Rate that applies to ABC braking in slow travel section 0-255100
124 Advanced Configuration # 2 Other important settings of the decoder - 21
bit description value
0 Wrong-: Maintain direction when changing direction.
not maintain direction
1
0
1 Decoderlock means CV 15/16 off Decoderlock means
CV 15/16 switched
02
2 Starting delay off switch starting delay 04
3 Serial protocol for C-Sinus off serial protocol for
C-Sinus switched
08
4 AUX9 output is active (only LokSound 5 H0) input wheel sensor is
turned on (only LokSound 5 H0)
0
16
5 Motor protection in blocking
The engine is not switched off at blocking the engine is
turned off a few seconds for blocking to avoid burnout
0
32
6 Reserved 64
7 Reserved 128
List of all supported CVs List of all supported CVs
