Esu 58410 - Page 18

18
Installing the decoder
Figure 1: 5 & LokSound LokSound 5 micro 8-NEM652 interface Polinger
58410 LokSound 5
front
Speaker # 1 Speaker
# 2 -Motoranschluss right
-Gleisanschluss right -
Rear light -U +
(positive pole) -
AUX1 (Power) -
Light Front
-Gleisanschluss left
-Motoranschluss left -
back
-- AUX8 (Power)
-- AUX7 (Power)
-- AUX6 (Power)
-- AUX5 (Power)
-- AUX4 (Power)
-- AUX 3 (Power)
-- VCC
-- AUX10 / wheel sensor
-- GND
-- AUX9 / PwrPackCtrl
-- U + (+ pole)
AUX9, AUX10 are logic level outputs and inputs
58810 LokSound micro 5
AUX7 is logic level output (Default: PwrPackCtrl)
pen assignment colour
1 Motor connection right orange
2 Rear light yellow
3 AUX1 green
4 Left track connection black
5 Left motor terminal Gray
6 Front light White
7 U + (Common return) blue
8th Right track connection red
5 4
1
1
4 5
2
3 6 7 8
Rear light ----------------
----------------- motor connection right
Speaker # 1 -----------------
Speaker # 2 ----------------
----------------- left motor terminal
Light ----------- front
---- right track connection
---- AUX1 (Power)
---- U + (+ pole)
---- AUX2 (Power)
---- left track connection
AUX9 Default: PwrPackCtrl
-- GND
-- U +
-- AUX2
(Power)
GND
-AUX7 -U + (+ Pol) -
-- VCC -- AUX5 (Pwr) -- AUX6 (Pwr)
