DOSING PUMPS EONE PLUS SERIES
Operating principle
The operation of the dosing pump is provided by a membrane in PTFE (Teflon ®) mounted on the piston of an
electromagnet. When the piston of the electromagnet is attracted, a pressure is produced in the pump body with an
ejection of liquid from the discharge valve. Once the electric impulse is over a spring returns the piston to its initial
position with a recall of liquid through the suction valve. Given the simplicity of operation the pump does not need
lubrication and requires very little maintenance. The materials used for the construction of the pump make it suitable for
the dosage of chemically aggressive liquids. The dosing pump is designed for capacities ranging from 1 to 30 l / h and
pressures of 4 to 20 bar depending on the model.
Technical Specifications
• Equipment manufactured in accordance with EC standards.
• External casing made out of plastic material resistant to acid and temperature.
• Control panel protected with serigraphic film.
• Multi voltage power supply 100-250 V 50-60 Hz
• Degree of protection: IP65
• Environmental conditions: indoors, maximum altitude 2000 m, room temperature from 5 ° C to 40 ° C,
maximum relative humidity 80% up to a maximum of 31 ° C (decreasing linearly until it is reduced to
50% at 40 ° C )
• Classification with respect to protection against direct contacts: CLASS I, the equipment is supplied with a
protective conductor
Reference Standards
The dosing pump complies with the following directives:
• 2006/95/EC: "Low tension"
• 2004/108/EC: "Electromagnetic compatibility"
Operating functions:
When first turned on the user can choose between different operation modes as best illustrated in the following
chapters. In general, the pump can operate in the modes specified in the following table.
Modes
one of the following operational functions:
• 1 x N: each impulse of the meter corresponds to the N injections of the pump.
• 1 x N(M): each meter impulse corresponds N of the pump, with storage for up to 4 * N
impulses from the meter during dosing.
• 1 / N: each N impulses of the meter corresponds to a single pump impulse.
• ml x imp: at each meter impulse the pump dispenses a pre-determined amount of
additive in millilitres.
• l x imp: at each meter impulse the pump dispenses a pre-determined amount of
PROPORTIONAL
ppm - ml x m
3
from the meter
The pump doses directly in ppm (Parts Per Million) or else in ml x m
3
(millilitres per cubic
metre). The device automatically carries out all calculations necessary to provide the required
concentration.
PROPORTIONAL
from mA input
The pump doses in proportion to a 4-20 mA current signal coming from an external transducer.
The setting of maximum and minimum values can be set in the respective set-up menu.
