PISA-E11 User`s Manual 5
 Temperature Monitor: One sensor close to CPU socket for
CPU temperature detection. One sensor close to 83627HF
chip for board temperature detection.
 One CPU FAN for CPU cooler and one SYS FAN for chassis
FAN. All FAN speeds are monitored.
 10/100M/1000M Ethernet:
 Two Realtek RT8111C chips on board for dual GbE LAN
support.
 Support Wake-on-LAN.
 Remote Boot Agent is supported with PXE or RTL protocol.
 PIDE and SATA:
 PIDE controller build in ICH7M support up to UltraDMA
mode 5 or ATA100 speed.
 One standard 44-pins Box header to support 2.5” HDD or
DOM Flash Disk.
 One Compact Flash-II socket shared with PIDE Channel. One
jumper to select as Master or Slave device.
 Two SATA connectors from ICH7M support SATA-I and
SATA-II devices.
 Watchdog Timer:
 The WatchDog timer can be disable/enable through BIOS
setup.
 The timeout interval 1~255 seconds can be programmed
through I/O address 842h/843h. The timeout event will
generate the RESET.
 CMOS:
 On-board RTC with 242 bytes of Battery-back CMOS RAM.
 One 3-pins Jumper for users to clear CMOS data.
 Audio:
 RealTek ALC888 High-Definition Audio chip on-board.
 One 10-pins pin-header to provide Line-out, Line-in and
Microphone functions.
 DIO:
 8-bits Digital I/O control. Support 8-In, 8-out or 4-In/4-out.
 BIOS:
 Award Standard PnP Flash BIOS 6.0.
 8Mbit FlashROM with BootBlock for Fail-safe.
 BIOS utility for field update.
 VBIOS and LAN remote Boot Agent integrated.
 PCI/ISA Interface:
 PISA bus version 1.7 complaint interface.
 Support Standard ISA interface except DMA mode operation
