LPT Port
The LPT parallel port is a standard DSUB 26-pins Female connector. It
can be configured as EPP or ECP or SPP mode.
Signal Name
Pin #
Pin #
Signal Name
Strobe
1
14
AUTOFD
DATA0
2
15
ERROR
DATA1
3
16
INIT
DATA2
4
17
SLIN
DATA3
5
18
GND
DATA4
6
19
GND
DATA5
7
20
GND
DATA6
8
21
GND
DATA7
9
22
GND
ACK
10
23
GND
BUSY
11
24
GND
PE
12
25
GND
SLCT
13
26
GND
IRDA Connector
This connector is used for an IrDA connector for wireless
communication.
IRDA Pin #
Signal Name
1
+5V
2
FIR
3
IR-RX
4
Ground
5
IR-TX
1
14
13
26
