PISA-E11 User`s Manual 15
INT_AUDIO Connector
Signal Name
Pin
#
Pin
#
Signal Name
JD0
1
2
NC
MIC1-IN-L
3
4
MIC1-IN-R
GND
5
6
GND
LINEOUT-L
7
8
LINE-IN-L
LINEOUT-R
9
10
LINE-IN-R
DIO Connector
DIO ports support 8 digital I/O bits. Each bit can be configured as
Input or output individually. All bits are 5V tolerant.
Signal
Name
Pin #
Pin #
Signal
Name
GND
1
2
+5V
DIO_0
3
4
DIO_4
DIO_1
5
6
DIO_5
DIO_2
7
8
DIO_6
DIO_3
9
10
DIO_7
