When you press [Combined Mode] on this item will show:
Phoenix-Award BIOS CMOS Setup Utility
On Chip IDE Device
IDE HDD Block Mode
[Enabled]
On-Chip Primary PCI IDE
[Enabled]
IDE Primary Master PIO
[Auto]
IDE Primary Slave PIO
[Auto]
IDE Primary Master UDMA
[Auto]
IDE Primary Slave UDMA
[Auto]
On-Chip Secondary PCI IDE
[Enabled]
IDE Secondary Master PIO
[Auto]
IDE Secondary Slave PIO
[Auto]
IDE Secondary Master UDMA
[Auto]
IDE Secondary Slave UDMA
[Auto]
*** On-Chip Serial ATA Setting***
SATA Mode
[IDE]
On-Chip Serial ATA
[Combined Mode]
x SATA PORT Speed Settings
Disable
PATA IDE Mode
[Secondary]
x PATA IDE Mode
PO, P2 is Primary
Item Help
Menu Level ►
If your IDE hard
drive suppers
block mode
select Enabled
for automatic
detection of the
optimal number
of lock
read/writes per
sector the drive
can support
↑↓← → ：Move Enter: Select +/-/PU/PD: Value F10:Save Esc: Exit F1:General
Help F5:Previous Value F6:Fail-Safe Defaults F7:Optimized Default
(Figure 12)
SATA Mode
Controls the SATA controller's operating mode.
The choice: IDE (default), RAID, AHCI.
PATA IDE Mode
This field is used to select the function mode of the IDE connector.
The only choice:
Secondary: IDE serves as Secondary Master and Secondary Slave
channel. SATA 1 and SATA 2 serve as Primary Master and Primary
Slave channel.
