PISA-E11 User`s Manual 13

2.2 Connectors on the PISA-E11

The connectors on the PISA-E11 allow you to connect external

devices such as keyboard, floppy disk drives, hard disk drives,

printers and etc. The following table lists the connectors on PISA-E11

and their respective page number.

Connector Locations on the PISA-E11 ........................................... 14

INT_AUDIO Connector .................................................................. 15

DIO Connector ............................................................................... 15

USB12, 34, 56 Connectors ............................................................. 16

INT_VGA Connector ...................................................................... 16

SATA1.2 Connectors ...................................................................... 17

VGA Connector .............................................................................. 17

LAN1, 2 GbE Connectors ............................................................... 18

ATX_PWR Connector ..................................................................... 19

INT_KBMS Connector .................................................................... 20

PS/2 Keyboard & Mouse Connector .............................................. 20

PWR_IN Connector ....................................................................... 20

FRONT_PANEL Connector ............................................................. 21

BACK LITE Connector ..................................................................... 23

System FAN Connector .................................................................. 23

CPU FAN Connector ...................................................................... 23

LVDS LCD Connector ..................................................................... 24

DVI Connector ............................................................................... 25

LPT Port ......................................................................................... 26

IRDA Connector ............................................................................. 26

CF-II Connector.............................................................................. 27

COM1, 3, 4 Serial Ports ................................................................. 28

COM2 Serial Port .......................................................................... 28

IDE Connector ............................................................................... 29
