38 PISA-E11 User`s Manual
Use the legend keys to navigate through this menu and exit to the
main menu. Use the Table listed below to configure the hard disk.
Item
Options
Description
IDE HDD
Auto-detection
Press Enter
Press Enter to auto-detect the
HDD on this channel. If
detection is successful, it fills
the remaining fields on this
menu.
IDE Channel 0 Master
None
Auto
Manual
Selecting ‘manual’ lets you set
the remaining fields on this
screen. Selects the type of fixed
disk. "User Type" will let you
select the number of cylinders,
heads, etc.
Note: PRECOMP=65535 means
NONE !
Access Mode
CHS
LBA
Large
Auto
Choose the access mode for
this hard disk
Capacity
Auto Display your
disk drive size
Disk drive capacity
(Approximated). Note that this
size is usually slightly greater
than the size of a formatted
disk given by a disk checking
program.
The following options are selectable only if the ‘IDE Channel 0 Master’ item is
set to ‘Manual’
Cylinder
Min = 0
Max = 65535
Set the number of cylinders for
this hard disk.
Head
Min = 0
Max = 255
Set the number of read/write
heads
Precomp
Min = 0
Max = 65535
**** Warning: Setting a value
of 65535 means no hard disk
Landing zone
Min = 0
Max = 65535
****
Sector
Min = 0
Max = 255
Number of sectors per track
