MOD OUTPUTS
A mod output is used to pass a high performance modulation signal from a module. A mod output may
be connected to any number of audio or mod inputs. Mod outputs are always found on the right side of
a module. See the comments made immediately above concerning the “low-fi” status of mod signals.
USEROBJECT OUTPUTS
Most modules have a userobject output. The userobject output can be connected to the userobject input
on a menupage module, the head module, or a gang module. Such a connection will allow the
module’s parameters to be accessible in the PARAMETER area. The existence or use of a userobject does
not affect system resources or memory. This means that menu pages can be created without using much
in the way of resources or program memory.
In Vsigfile, userobject outputs are always found on the right side of a module. In the Patch Editor area,
userobject outputs are not explicitly shown.
USEROBJECT INPUTS
A handful of modules (gang, head, and menupage) have userobject inputs. This means that these
modules can accept as inputs other modules’ userobject outputs. For instance, a menupage module
may be used to create a
PARAMETER area menu page by accepting the userobjects of other modules.
In Vsigfile, userobject inputs are always found on the left side of a module. In the Patch Editor area,
userobject inputs are not explicitly shown.
