Image 4: LCD home screen
End Transaction / Coin Return Button
The end transaction button and the coin return button are identical, except that the coin return
button also performs a mechanical unjamming function by physically moving parts and levers
within the coin manager, so that jammed coins can be dislodged.
Otherwise, both buttons perform exactly the same function. When you are in cash mode, and
there is any balance remaining on the screen, then pressing will give change and end the
transaction. When you are in manager mode or credit card mode, then pressing will end the
transaction.
Ice Vend / Water Vend Buttons
These two buttons are similar except that one initiates an ice vend and the other initiates a
water vend. As soon as you press the vend button of choice, money is deducted from the LCD
balance and the vend type selected will be immediately started. There is no additional step of
warning to place a water container or ice container in place.
Ice Out Light
If the machine does not have enough ice to provide a full vend, the “Out of Ice When Lit” light
will be illuminated.
Ice Output Chute
The ice output chute is where the ice is dispensed. The user is responsible for preparing an
open ice bag or ice cooler to capture the ice before pressing the ice vend button.
Warning: Do not insert anything into the ice chute while ice is dispensing. There are moving
parts within the internal chute which may be jammed or cause injury.
Water Dispenser Nozzle
The water dispense nozzle is where water is dispensed. The user is responsible for preparing a
container to capture the water before pressing the water vend button. The water vend nozzle is
positioned inside a water dispense housing that has a shelf for holding containers and also has
a built-in drain for excess spilled water.
Bag Opening
