ECOR960 4F2 / 8F2 / 16F2
No. Name Description
1 USB2.0 Port
The USB2.0 ports for connecting to a mouse or external storage
device.
2 View Press the type of layout you want for displaying your channel feeds.
3 SEQ (Sequence)
Press to enter the automatic sequence mode. This will show each
channel feed in sequence.
4 Display
Press to cycle between the info display types (channel and status bar
info).
5 Search Press to enter the Search Setup menu.
6 Copy Press to enter the Copy Menu.
7 Zoom
Press repeatedly to toggle between 2x and 4x zoom. Press the Menu
button to switch zoom off.
8 Arrow Keys Use these arrow keys to change the Menu settings.
9 IR Receiver Receiver for IR Remote Control.
10 Status LED
Power LED: Indicates the power is on.
Record LED: Indicates the DVR is recording.
Alarm LED: Indicates the alarm input is triggered. (Note: ECOR960
16F2 doesn’t have the Alarm LED).
11 Menu Press to enter/exit the Main Setup Menu.
12
1~8 / 9~16
Press to display the channel in full screen.
13 Channel Switch
Press this button to switch the above channel button numbers
between 1~8 and channel 9~16.
