ECOR960 4F2 / 8F2 / 16F2
9
No. Name Description
1 Video Input Connect up to 4 / 8 cameras using the coaxial cables.
2 Call Monitor Port (BNC) Connects to the Call monitor using a BNC cable.
3 Audio Input 1~2 (RCA)
Connects to the audio input devices such as microphones.
Note that the microphone with a (built-in) amplifier and
external power supply is required.
4 Main Monitor Port (VGA) Connects to the Main monitor using a VGA cable.
5 Alarm Input / Output Connects to 4 alarm inputs, and to 1 alarm output device.
6 Power Press to turn on or off the power.
7
Audio Output BNC
(4F2/8F2)
Audio Output RCA (16F2)
If it is a BNC connector, please connects to the audio output
devices, such as speakers, using the supplied BNC to RCA
Connector. Note that the speaker with a (built-in) amplifier
and external power is required.
8 Main Monitor Port (HDMI) Connects to the Main monitor using a HDMI cable.
9 LAN Connects to the Network.
10 USB Interface
Con
nects to USB storage device to copy / archive video or for
firmware upgrades. Use the other port for connecting the
mouse.
11 RS-485 Port
Connects to the RS-485 device, such as EverFocus’ EKB-500
keyboard.
12 Power Port
Connects to the DC 12V power using the supplied Power
Cord.
13
Audio Input 3~4 (4F2)
Audio Input 3~8 (8F2)
Audio Input 3~16 (16F2)
Connects to the audio input devices using the supplied Audio
Cable.
