Appendix F: SATA Board Installation
1. Install SATA board to HDD
A. HDD
B. Bridge Chip
C. SATA board
 Screw the SATA board to
Bridge Chip.
 Fix the Bridge
Chip with SATA board
to HDD.
2. Install HDD with SATA board to HDD tray:
Appendix
F
C
B
A
○
2
○
○
2
○
3
○
○
3
○
4
○
4
○
1
