9
99
9
VGA
10
VGA
Connect to the monitor that has VGA input.
REMOTE CONTROL (extension cable is optional)
11
Remote Control
Connector for IR extension cable that has an IR remote control receiver.
AUDIO
12
Audio IN
Audio inputs 1~4 for recording, and it can be enabled by setting to “YES” or “NO” in
the RECORD SETUP MENU.
Audio OUT
Connect an audio output to a monitor or other device. Audio 1 corresponds to CH 1,
audio 2 corresponds to CH 2, audio 3 corresponds to CH 3 and audio 4 corresponds
to CH 4.
SCSI (Only available for EDVR16D3)
13
SCSI Connector
For connecting the optional external hard drive array (EDA800).
S-VIDEO (Only available for EDVR16D3)
14
S-Video
Provides S-Video connector.
