evertz HDSD9545DLY-PRO - Overview of Operation; Figure 3-2: Operational Overview

HDSD9545DLY - PRO Profanity Bypass Delay Manual
OPERATION Revision 1.3.7 Page 3-3
3.2. OVERVIEW OF OPERATION
1. Profanity coming
2. Profanity Observed
3. Trigger Button ACTIVATED
Activation Reaction Time
Time to Switch
to Safe Feed:
Tdelay-Activation
Reaction Time
5. Output Switches to 'Safe' feed
High =
Button Activation
4. Trigger Button RELEASED
Activation Reaction Time
High =
Button Activation
Time to Switch
back from safe Feed:
Tdelay+Fixed Safety Margin
6. Mux Switches back to PGM
Upstream Video Path HDSD9545DLY-PRO
HDSD945DLY-PRO
Demark Point
Safe Feed
Live Feed
Safe Feed
Live Feed
Safe Feed
Live Feed
Safe Feed
Live Feed
Safe Feed
Live Feed
Safe Feed
Live Feed
Figure 3-2: Operational Overview
