HDSD9545DLY - PRO Profanity Bypass Delay Manual
OPERATION Revision 1.3.7 Page 3-7
3.6.1. Configuring the Video Outputs
There are three identical menu items used to select the function of the Video A, Video B, Video C, Video D
and Video E outputs. Configuring the outputs for each of the buses is done in the same manner, but for
simplicity, only the Video A menu will be shown in the manual.
OUTPUT
Video A
Vid A:pgm
Vid A:safe
Vid A:dly pgm
Vid A:dly safe
Vid A:on air
Vid A:quad split
This menu item configures the Video Outputs.
The program input (A) video is being output on the VID A output
The safe input (B) video is being output on the VID A output
The delayed program input (A) video is being output on the VID A output
The delayed safe input (B) video is being output on the VID A output
The on air program video is being output on the VID A output
The quad split is being output on the VID A output
The default signal for OUTPUT A is the On air (on air) video. The default signal for OUTPUT B is the
Delayed Program (dly pgm) video. The default signal for OUTPUT C is the Delayed Safe (dly pgm) video.
The default signal for OUTPUT D and OUTPUT E is the quad split (quad split) output showing the two
video inputs and their delayed feeds.
3.6.2. Configuring the Audio Outputs
There are three identical menu items used to select the function of the AES A, AES B and AES C outputs.
Configuring the outputs for each of the buses is done in the same manner, but for simplicity only the
AES A menu will be shown in the manual.
OUTPUT
AES A
AES A:pgm
AES A:safe
AES A:dly pgm
AES A:dly safe
AES A: on air
This menu item configures the Audio Outputs.
The program input (A) AES audio is being output on the AES A output
The safe input (B) AES audio is being output on the AES A output
The delayed pgm input (A) AES audio is being output on the AES A output
The delayed safe input (B) AES audio is being output on the AES A output
The on air input AES audio is being output on the AES A output
The default signal for AES A is the On air (on air) AES. The default signal for AES B is the Delayed
Program (dly pgm) AES. The default signal for AES C is the Delayed Safe (dly pgm) AES.
3.7. CONFIGURING THE ON SCREEN DISPLAY
The OSD menu items are used to configure the on screen displays. The chart below shows the items
available in the OSD menu. Section 3.10.1 provides detailed information about the sub-menu.
Enable/Dis.
Enables or disables the on screen displays
