HDSD9545DLY - PRO Profanity Bypass Delay Manual
Page 3-10 Revision 1.3.7 OPERATION
TRANSITION
Gpi 1
Clear All
tot video switch
act video switch
blank vid sw
hblank vid sw
pgm blur
safe blur
aes-# switch
emb smute g#c#
aes-# smute
aes-a# hmute
aes-b# hmute
aes-c# hmute
t tot video sw
t act video sw
t blank vid sw
t hblank vid sw
t pgm blur
t safe blur
t aes-# switch
t e smute g#c#
t aes-# smute
t aes-a# hmute
t aes-b# hmute
t aes-c# hmute
video bypass
audio bypass
safe capture
A list of the possible transitions is shown below.
Clear all transitions for this trigger or tally
Immediately switches the ‘on air’ video (including embedded audio and
ancillary data) from the Program to the Safe video.
Immediately switches the ‘on air’ active video (excluding embedded audio
and ancillary data) from the Program to the Safe video.
Transitions both the h blanking and v blanking between the program feed
and safe feed.
Transitions only the h blanking (embedded audio) between the program
feed and safe feed.
Immediately blurs the program delayed video by the amount set by the
Pgm Blur Factor menu item.
Immediately blurs the safe delayed video by the amount set by the
Safe Blur Factor menu item.
Immediately switches the ‘on air’ audio from the Program AES to the Safe
AES audio.
Immediately fades the embedded audio to silence. Select the group and
channel to be muted.
Immediately fades the ‘on air’ AES audio to silence. Select the pair to be
muted.
Immediately mutes the audio on the AES A outputs. Select the pair to be
muted.
Immediately mutes the audio on the AES B outputs. Select the pair to be
muted.
Immediately mutes the audio on the AES C outputs. Select the pair to be
muted.
The Timed Transitions perform the same functions as the Immediate
Transitions above but are delayed by the amount of the Program Delay
minus the Reaction Time.
Immediately activates the video bypass mode selected by the Bypass mode
menu item.
Immediately activates the audio bypass relays.
Captures video to be used by the Safe Input when the Frame, or Loop mode
is enabled. The length of the capture buffer is equal to the length set for the
safe delay.
Operation:
Safe Mode = Repeat Frame: When active, causes live safe video to be routed directly to the safe delayed
input. When inactive, the safe delayed input freezes on the last frame.
Safe Mode = Cont. Loop: A momentary activation causes the buffer to begin recording until it is full.
Safe Mode = Loop on Switch: (Same as Cont. Loop)
