XRF1/XRF1A 16x16 RF Router Manual
XRF1 - 4-2 Revision 1.2 FRONT PANEL INTERFACE
4.1.1.2. Salvo Selection Mode
This mode is initiated by pressing the [INPUT] and [OUTPUT] buttons simultaneously. It accesses up to 8
pre-programmed salvos that have been configured using Evertz VistaLINK
®
software.
A SALVO is a pre-programmed sequence of crosspoint connections that can be constructed using
VistaLINK
®
and executed from the XRF1 Control Panel. Execution of a salvo is very similar to the
execution of an individual crosspoint connection, but the entire list of connections contained in the salvo is
performed. The following table outlines the operations performed by each button while in Salvo Selection
Mode.
Button/Process
Action While in Salvo Selection
Mode
Resulting Action
0-9 NUMERIC, SCROLL KNOB
Select salvos Displays selected salvo
[TAKE]
Performs physical group of
crosspoint changes within router for
currently selected salvo
Returns to Salvo Selection Mode
[OUTPUT]
Toggles to Destination Selection
Mode
Displays last manipulated
destination
[INPUT]
Toggles to Source Selection Mode Displays last manipulated source
[MENU]
Initiates Configuration Menu Mode
Displays passcode prompt, if
enabled
30 SECONDS OF INACTIVITY
Panel times out
Returns to Destination Selection
Mode
Table 4-2: Button Operations for Salvo Selection Mode
4.1.1.3. Source Selection Mode
This mode is initiated by pressing [INPUT]. This mode is used to select matrix sources (router inputs). The
following table outlines the operations performed by each button while in Source Selection Mode.
Button/Process
Action While in
Source Selection Mode
Resulting Action
0-9 NUMERIC, SCROLL KNOB
Select sources Displays selected source
[TAKE]
Performs physical crosspoint change
within router for currently selected
input/output pair
Returns to Destination Selection
Mode
[INPUT], [ENTER]
Toggles to Destination Selection
Mode
Displays last manipulated
destination
[MENU]
Initiates Configuration Menu Mode
Displays passcode prompt, if
enabled
30 SECONDS OF INACTIVITY
Panel times out Returns to Source Selection Mode
Table 4-3: Button Operations for Source Selection Mode
