XRF1/XRF1A 16x16 RF Router Manual
FRONT PANEL INTERFACE Revision 1.2 XRF1 - 4-9
4.3.1.5. Name Display when in Configuration Menu Mode
When a user presses [MENU], they are prompted for a passcode (if enabled). Refer to section 4.3.2 of this
document for further explanation of this passcode protection. After the user passes the code protection
feature of the Configuration Menu, they are prompted to select the input channel they are wishing to
access parameters for. The display prompt will look like the following example:
Entering a number from the 0-9 keypad takes the user directly to that input channel. For example, if the
source named “TELSTAR 12” is on input channel 5, pressing #5 on the keypad would result in the following
display:
From the “SELECT INPUT” prompt, one rotation of the scroll knob clockwise or pressing the down arrow
displays input channel 1. If the source on input channel 1 has been named “TELSTAR 20,” the display
would show the following:
From the “SELECT INPUT” prompt, one rotation of the scroll knob counter-clockwise or pressing the up
arrow displays input channel 16 (or 32). If the source on input channel 16 (or 32) has been named
“TELSTAR 15,” the display would show the following:
4.3.2. Display Function in Passcode Prompting
The XRF1 Control Panel has 3 passcode-protected features: the Configuration Menu, Destination Lock and
Salvo Lock. When passcode protection has been enabled, through VistaLINK
®
, for any of these functions,
the display screen visually prompts the user for the passcode necessary to access these features. If no
passcode protection has been setup through VistaLINK
®
, no prompting will occur and the user will be free
to directly access any of these features.
SELECT INPUT
5 TELSTAR 12
1 TELSTAR 20
16 TELSTAR 15
