XRF1/XRF1A 16x16 RF Router Manual
FRONT PANEL INTERFACE Revision 1.2 XRF1 - 4-11
The user now enters the passcode using the 0-9 numeric buttons and the control panel returns to
Destination Selection Mode:
If the user enters the incorrect passcode, the screen will display a 2-second message that will look like this:
After 2 seconds, the screen will once again display the passcode prompt:
If a user presses [TAKE] for a crosspoint pair that includes a “locked” destination, the display will prompt for
the passcode again:
If the user enters a valid passcode, the display will return to provide the status of the current crosspoint pair
and a successful “take” can then be executed.
"
Refer to Figure 5-4 for the operational flow for accessing the destination Lock
feature.
4.3.3. Display Function in Confirmation Messaging
The XRF1 Control Panel has two possible confirmation messages.
From Source Selection Mode, Destination Selection Mode, or Salvo Selection Mode, a successful “take”
will result in the following display for 2 seconds:
STAR 12 IRD 16
INVALID CODE
LOCK CODE?
UNLOCK CODE?
TAKE SUCCESSFUL
