XRF1/XRF1A 16x16 RF Router Manual
FRONT PANEL INTERFACE Revision 1.2 XRF1 - 4-3
4.1.1.4. Configuration Menu Mode
This mode accesses the router Configuration Menu. The Configuration Menu is passcode protected only if
the user has enabled this feature through VistaLINK
®
. If enabled, pressing [MENU] prompts the user for an
Administrator-level passcode. Entry of the proper passcode accesses router control and configuration
parameters. If passcode protection has not been enabled, pressing [MENU] takes the user directly to
Level 1 of the Configuration Menu. Selecting the “exit” option from menu Level 2 terminates Configuration
Menu Mode.
The following table outlines the operations performed by each button while in Configuration Menu Mode.
Button/Process
Action While in Configuration
Menu Mode
Resulting Action
[ESC]
Moves up one menu level. At the
top level of the configuration menu,
it will exit this mode and return to
Destination select menu mode
(default)
Displays higher menu level or exits
menu mode to default
0-9 NUMERIC
Selects source channel Displays selected source channel
SCROLL KNOB
Navigates menu options Displays selected option
[INPUT] and/or [OUTPUT]
Exits Configuration Menu Mode,
and enters Source, Destination, or
Salvo Selection Mode
Displays last manipulated source,
destination, or salvo
[ENTER]
Finalizes option selection and
moves down one menu level
Displays first option in subsequent
menu level
[MENU]
Returns user to Menu Level 1 (Input
Channel Selection)
Displays “SELECT INPUT”
30 SECONDS OF INACTIVITY
Panel times out Returns to Destination Selection Mode
Table 4-4: Button Operations for Configuration Menu Mode
4.1.1.5. Configuration Set Mode
This mode defines the operation of the XRF1 while in the lowest menu level, where parameters such as
gain and output levels can be set from within the Configuration Menu. The following table outlines the
operations performed by each button while in Configuration Set Mode.
