XRF1/XRF1A 16x16 RF Router Manual
CONTROL PANEL OPERATION Revision 1.2 XRF1 - 5-3
"
When the user exits Source Selection Mode, or after 30 seconds of inactivity, the
XRF1 Control Panel returns to Destination Selection Mode.
5.3. [OUTPUT] SELECT FUNCTION
5.3.1. [OUTPUT] Function from Source Selection Mode
Press [OUTPUT]
This toggles to Destination Selection Mode.
5.3.2. [OUTPUT] Function from Salvo Selection Mode
"
[INPUT] and [OUTPUT] are pressed simultaneously to initiate Salvo Selection Mode
(from within Salvo Selection Mode)
Press [OUTPUT]
This exits Salvo Selection Mode and enters Destination Selection Mode.
5.3.3. [OUTPUT] Function from Configuration Menu Mode
Press [OUTPUT]
This exits the Configuration Menu and enters Destination Selection Mode.
5.3.4. [OUTPUT] Function from Configuration Set Mode
Press [OUTPUT]
This exits Configuration Set Mode, without making configuration changes and enters Destination Selection
Mode.
5.4. [MENU] FUNCTION
The XRF1 user has the option to enable passcode protection, through VistaLINK
®
software, limiting access
to Configuration Menu Mode. Setting and enabling of the menu passcode is processed only through
Evertz’s VistaLINK
®
. The XRF1 is only responsible for querying the user for the passcode when required.
When passcode protection has been enabled, pressing [MENU] prompts for an Administrator-level 4-digit
passcode. If passcode protection is never enabled through VistaLINK
®
, pressing [MENU] will enter the
Configuration Menu directly. Refer to Figure 5-3 for the operation flow for accessing the Configuration
Menu Mode.
5.4.1. [MENU] Function from Source and Destination Selection Modes –
Passcode Protection Enabled
Press [MENU]
When enabled, this action displays a prompt for the 4-digit Administrator-level passcode.
The user enters the passcode configured through VistaLINK
®.
Press [ENTER]
Initiates Configuration Menu Mode and prompts for input channel selection.
