XRF1/XRF1A 16x16 RF Router Manual
FRONT PANEL INTERFACE Revision 1.2 XRF1 - 4-15
4.5.4. CONFIGURE INPUT Menu Options and Parameters
LEVEL1:
PARAMETER DESCRIPTION
All Inputs
Allows configuration of all inputs
Channel 1 to 16
Input channel selection
Table 4-12: Configure Input Menu Options
LEVEL 2: (options available for ALL INPUTS or individual input channel as selected in Level 1)
PARAMETER DESCRIPTION
Input Level
Statuses current input level -5dBm to -70dBm
Output Level
Accesses output level setting -20dBm to -50dBm in increments of 1dBm in
AGC MODE only.
Gain Mode
Accesses AGC MODE and MANUAL GAIN MODE options.
Gain
Accesses manual gain (+18 to –6dB on XRF1, or +12 to –10dB on XRF1A, in
1dB steps) in MANUAL. GAIN MODE only
Squelch
Accesses ON or OFF options.
RF Threshold
Accesses UPPER, LOWER, and SQUELCH threshold settings.
LNB Power (-LNB
option only)
Accesses +13V / +18V / OFF settings for LNB.
LNB Reset (-LNB
option only)
Accesses reset of LNB power after a short circuit detect.
Table 4-13: Options Available for ALL INPUTS or Individual Input Channel
as Selected in Configure Input Menu Level 1
LEVEL 3 ( RF THRESHOLD MENU ITEMS ):
PARAMETER DESCRIPTION
Upper
1dBm increments, from –5dBm to –30dBm
Lower
1dBm increments, from - 70dBm to –31dBm
Squelch
1dBm increments, from –70dBm to –50dBm
Table 4-14: RF Threshold Menu Options
