Excell EX-2001 Racer Plus - 7-5 OP-06 RS-232 & Current Loop

EX-2001 Plus v1.3 SME300000060
30
EXCELL PRECISION CO., LTD.
FG
RxD
TxD
SG
+ AC
- AC
C.LOOP
C.LOOP
1
2
3
4
5
7
12
13
CONNECTION
7-5 OP-06 RS-232 & CURRENT LOOP
2 RS-232 / Current Loop
RS-232C is a bi-directional output/input; Current Loop is one-way output only,
and the output data format is the same as RS-232.
