9-3 OP-02 BCD OUTPUT INTERFACE FUNCTION
SET VALUE
FUNC. NO. FUNCTION
PARAMETER
DESCRIPTION
DEFAULT
0 As displayed
1 Gross
FUNC. 80 Data type
2 Net
0
0 Stream transmit
1 Auto-transmit
FUNC. 81 Transmit mode
2
Press the key to transmit
0
0 Positive logic
FUNC. 82
Output data
logic
1 Negative logic
0
0 Positive logic
FUNC. 83 Signal logic
1 Negative logic
0
9-4 OP-03 ANALOGUE OUTPUT INTERFACE FUNCTION
SET VALUE
FUNC. NO. FUNCTION
PARAMETER
DESCRIPTION
DEFAULT
0 As displayed
1 Gross
FUNC. 85 Data type
2 Net
0
FUNC. 86
Low point of
weight value
000000
↓
999999
0
FUNC. 87
Low point of
output current
value
0.0 mA
↓
20.0 mA
When the weight value
reaches the val
ue set in Func.
86, the current output
is the value set in Func. 87
4.0 mA
FUNC. 88
High point
Weight value
000000
↓
999999
16000
FUNC. 89
High point
Output current
value
0.0 mA
↓
20.0 mA
When the weight value
reaches the valu
e set in Func.
88, the current output
is the value set in Func. 89
20.0 mA
