EX-2001 Plus v1.3 SME300000060

EXCELL PRECISION CO., LTD.

CONTROL

1 2

INPUT

OUTPUT

1 2

IN / OUTPUT

OUTPUT 1~4

12V

30VDC/250VAC

+12V

INPUT 1~2

7-7 OP-08 CONTROL I /O (2I /4O) INTERFACE

2 External input and relay output

Output Pin Function

1 : Zero Band

2 : Hi

3 : Ok

4 : Lo

Input / output connectors on the rear panel

The output circuit of Relay

The input circuit
