9-2 OP-01, OP-06, OP-07 INTERFACE FUNCTION
SET VALUE
FUNC. NO. FUNCTION
PARAMETER
DESCRIPTION
DEFAULT
0 As displayed
1 Gross
2 Net
FUNC. 60 Data type
3 Tare
0
0 Stream transmit
1 Auto-transmit
2
Press t key to transmit
3
Command mode
(without address)
FUNC. 61 Transmit mode
4
Command mode
(with address)
0
0 1200
1 2400
2 4800
3 9600
FUNC. 62 BAUD rate
4 19200
1
0 N, 8, 1
No parity bit,
8 data bit, 1 stop bit
1 O, 7, 1
Odd parity bit,
7 data bit, 1 stop bit
FUNC. 63
Parity bit
Data bit
Stop bit
2 E, 7, 1
Even parity bit,
7 data bit, 1 stop bit
2
0 None
1 kg
2 g
3 t
FUNC. 64 Units
4 lb
1
0 Continuous output
FUNC. 65
Unstable or
over the max.
capacity
1 Stop output
0
0
Positive
(more than + 5D)
FUNC. 66
Auto-transmit
conditions
1
Positive / negative
(more than + 5D,
less than - 5D)
0
FUNC. 67
Command
address
00
↓
99
When the FUNC. 61 is set in
4, it will use this address
0
0 Standard Format
FUNC. 68 Output format
1 UMC 600
0
0 W/o limit
1 1 Time/ Sec.
2 2 Times/ Sec.
3 5 Times/ Sec.
4 10 Times/ Sec.
FUNC. 69
Transmit
frequency
5 20 Times/ Sec.
4
0 Close RS422/485
FUNC. 70 Output type
1 Start RS422/485
0
