EX-2001 Plus v1.3 SME300000060
5
EXCELL PRECISION CO., LTD.
Fn
Fn
CAL
CAL
Fn
CAL
CHAPTER 2 OPERATION GUIDE
FUNCTION OPERATION PROCEDURE DESCRIPTION
General function
setting
Press and hold the key,
then press the
Refer to Chapter 9
to set FUNC. 0 ~ FUNC. 7
Capacity parameter
setting
Switch the capacity calibration
switch to “ON”
and then press the
Set the parameter for decimal
point, max. capacity, min. division,
zero tracking, unstable detection
Refer to < 5-1 > Parameter Setting
Calibration
Switch the capacity calibration
switch to “ON”
and then press the
Calibration procedures.
Refer to < 5-2 > Calibration Setting
Self-diagnosis mode
Turn on the indicator,
press and hold and
the indicator starts the self-test
procedure.
Refer to < 8-3 > Self-diagnosis
Mode for details
Reset all parameters
back to default
Switch the calibration switch to
“ON”, turn on the indicator,
while the indicator is in the
self-testing sequence
Refer to < 8-1 > Reset All
Parameter Back to Default
Reset general function
parameter back to
factory standard setting
Turn on the indicator,
press and hold
by pressing
while the indicator is in the
self-testing sequence
Refer to < 8-2 > Reset General
Function Parameter Back to
Default
Display software version
Turn on the indicator,
press and hold the
while the indicator is in the
self-test sequence
The main display section displays
the software version,
to exit
Function parameter
setting
Press and hold ,
followed by pressing
Hi, Lo, Zero Band parameter
setting
To Next Page
