CHAPTER 1 SPECIFICATIONS
ANALOG DATA
Input sensitivity 0.12 μV／D or more
Max. load cell input voltage -1mV〜16mV
Load cell excitation DC 5V
Load cell current 120mA ( 8- 350Ω load cells )
Zero -14.49 ppm/℃ ( -10℃〜40℃)
Temperature coefficient
Span
-1.65 ppm/℃ ( -10℃〜40℃)
Non-linearity ±0.002％FS
Input noise 8nV⁄√Hz f = 10KHz
Input impedance 250GΩ
Internal resolution 520000
Max. display resolution -999999〜999999
Conversion rate 100 times/sec (max.)
DIGITAL DATA
Display section 7 digits, red LED, 20mm (0.8”), 7-segment
Status display section 6 character display, red LED
Display frequency (times/sec) Selectable, Max 50
Display range -999999 to 999999
Min. division 1, 2, 5, 10, 20, 50
Status display Power, Zero, Motion, Gross, Net, Tare
Decimal point Selectable 0, 0.0, 0.00, 0.000, 0.0000
GENERAL SPECIFICATIONS
Power requirements (AC/W)
AC100V〜240V -15%~＋10% 10W
Operating temperature range
－10℃〜＋40℃
Operating humidity range
＜85％ R.H
Physical dimensions 210(W) × 108 (H) × 207(D)
Weight About 1.7 kg
OPTIONS
OP-01 RS422 / RS-485
OP-2-1 Parallel BCD Output ( TTL )
OP-2-2 Parallel BCD Output ( O.C. )
OP-03 Analog Output ( 4 - 20mA )
OP-05 Parallel Printer Output / RS232C & Current Loop
OP-06 RS-232C & Current Loop
OP-07 RS-232C & Current Loop & Data Clock Output
OP-08 Control I / O ( 2I / 4O)
