EXCELL PRECISION CO., LTD
Function Operation Display Description
Check weighing setpoint
parameter setting
Press the key to set
the parameter of FUNC.4 to 1 in
the normal mode
.
or
.
See 4-2 for details
Key actions in function set up mode
⇒ Increases the number of the flashing digit
⇒ Decreases the number of the flashing digit
⇒ Moves the flashing digit one space to the left
⇒ Moves the flashing digit one space to the right
⇒ Saves the configuration
⇒ Quits set up mode / Escape
2-2 Error Messages (Display in General Function setting)
. ⇒ Load Cell output voltage < - 0.1m V / V or > 4mV / V
. ⇒ Weight value ≤ previous weight value
. ⇒ Actual measured weight value ≤ previous weight value
. ⇒ Setting value 0
. ⇒ mV / V value entered > measuring range
. ⇒ mV / V value entered is too small (SPAN – Zero < 0 mV / V)
. ⇒ Displayed resolution is less than 0.12 μV / division
To Next Page
