Excell EX2005 User Manual

71
04011210
EXCELL PRECISION CO., LTD
ZSME400000003
Appendix 4 MODBUS Data Address Table II
(For Hitech and Pro-face Human Machine Interface)
Data Register Bit I/O Bit I/O
Function Code 03 (Read) Function Code 01 (Read) Function Code 05 and 15 (Write)
Modbus SCALE Modbus SCALE Output Modbus SCALE Input
40001 ~ 40002 As display value 00001 Stable status 01001 Zero
40003 ~ 40004 Gross weight 00002 Zero status 01002 Clear zero compensation
40005 ~ 40006 Net weight 00003 Gross 01003 Tare
40007 ~ 40008 Tare weight 00004 Net 01004 Clear Tare
40009 ~ 40010
Gross weight
hold value
01005 Clear Pre-tare
40011 ~ 40012
Net weight
hold value
00051 Zero Band 01006
Display the gross weight on
main display
40013 ~ 40014
Weight final
value
00052 Sp1 01007
Display the net weight on
main display
40015 ~ 40016 Unit weight 00053 Sp2 01008
Enter/Exit the function
mode
40017 ~ 40018
Percentage
value
00054 Sp3
01009 ~ 01028
Switch unit
from the 1
st
to 20
th
40019 ~ 40020 Totalised value 00055 Batch Finish
40021 ~ 40022 Totalised times 00056 Under 01050 Switch the operation modes
40023 ~ 40024
Totalised times
of HI value
00057 Over 01051
Totalised the current net
weight and add 1 to the
totalised times
40025 ~ 40026
Totalised times
of Lo value
00058 Unloading 01052
Deduct the last totalised
value and deduct 1 to the
totalised times
40027 ~ 40028
Totalised times
of OK value
00059 Hi-Hi 01053
Clear the totalised value
and times
00060 Hi 01054 Running
Function Code 06 and 16 (Write)
00061 Go 01055 Stop
41001 ~ 41002 Pre-tare value 00062 Lo 01056 Discharge starts
41003 ~ 41004 Zero Band value 00063 Lo-Lo 01057 Hold mode ON/OFF
41005 ~ 41006 Target value 00064 Peak ready 01058 Release "Hold value"
41007 ~ 41008 SP1 value 00065 Running 01059 Output judgement
41009 ~ 41010 SP2 value 00066 ZERO calibration 01060 ZERO calibration
41011 ~ 41012 SP3 value 00067 SPAN calibration 01061 SPAN calibration
41013 ~ 41014 LO_LO value 00068 Calibrate ERR0
41015 ~ 41016 LO value 00069 Calibrate ERR2
41017 ~ 41018 HI_HI value 00070 Calibrate ERR6
41019 ~ 41020 HI value
41021 ~ 41022 Under value
41023 ~ 41024 Over value
41025 ~ 41026
Peak value
setting
41101 ~ 41102
SPAN calibration
value
 The settings marked in grey are not available.
