EXCELL PRECISION CO., LTD
3-6 Linearity calibration
Before the Linearity calibration, the General calibration should be completed.
Set CAL switch to ON
Select linearity calibration
Press the key
Select one of five calibration, and
Press the key
Press the key
When stable, the display area shows
the modified weight value
Please refer to the error message list if the display shows . X .
⇒ Increment flashing digit
⇒ Decrement flashing digit
⇒ Move flashing point left.
⇒ Move flashing point right
⇒ Store data in memory
⇒ Exit / Escape
Use to select one of
calibration points (1P~5P)
: no setting value
: with setting value
Press the key
Press the key
Key in the correct weight value
Press the key
Press the key
.
. . . . .
Finish the 1
st
calibration point
setting. Either continues the
second point calibration or
press key to exit the
linearity calibration process
To Next Page
