EXCELL PRECISION CO., LTD
4-3 Batching Signal Outputs
 Normal batching signal outputs
Signal Output condition
SP1
Net ≥ Final(value) - SP1(value)
SP2
Net ≥ Final(value) - SP2(value)
SP3
Net ≥ Final(value) – Free Fall (in-flight) (value)
Under
Net < Final(value) – Under(value)
Over
Net ≥ Final(value) + Over(value)
Zero Band
Gross ≤ Zero Band(value)
 Loss-in-weight signal outputs
Signal Output condition
SP1
Gross ≥ SP1(value)
SP2
- Net ≥ Final(value) – SP2(value)
SP3
- Net ≥ Final(value) – Free Fall (in-flight) (value)
Under
- Net < Final(value) – Under(value)
Over
- Net ≥ Final(value) + Over(value)
Zero Band Gross ≤ Zero Band(value)
 Hi, OK, Lo signal outputs
Setting
SQ01 SQ16
Signal Output condition
1,2,4,5 1,3
Net < Final(value) – Under(value)
3 0,2,4
Under
Net <Lo(value)
1,2,4,5 1,3
Net ≥ Final(value) + Over(value)
3 0,2,4
Over
Net ≥ HI(value)
1,2,4,5 1,3
Final(value) – Under(value)≤Net
< Final(value) + Over(value)
3 0,2,4
OK
Lo(value)≤Net<Hi(value)
1,2,4,5 1,3
Net < Final(value) – Under(value)
3 0,2,4
LO
Net < Lo(value)
1,2,4,5 1,3
Net ≥ Final(value) + Over(value)
3 0,2,4
HI
Net ≥HI(value)
