Excell EX2005 User Manual

39
04011210
EXCELL PRECISION CO., LTD
ZSME400000003
 Connection type
RS-422
SDA
SDB
RDA
RDB
SG
电脑主机
EX- 2002
RS2-7=01
DA
DB
SG
RS- 485
EX- 2002
RS2-7=02
EX- 2002
RS2-7=10
EX- 2002
RS2-7=10
EX- 2002
RS2-7=02
EX- 2002
RS2-7=01
SDA(1)
SDB(2)
RDA(3)
RDB(4)
SG(6)
TRM(5)
TRM(5)
SG ( 6
)
RDB(4)
RDA(3)
SDB(2)
SDA(1)
TRM(5)
SG(6 )
RDB(4)
RDA(3)
SDB(2)
SDA(1)
TRM (5)
SG (6)
RDB(4)
RDA(3)
SDB(2)
SDA (1)
TRM(5)
SG (6)
RDB(4)
RDA(3)
SDB (2)
SDA(1)
TRM(5)
SG (6 )
RDB(4)
RDA(3)
SDB(2)
SDA(1)
电脑主机
 Notice:
z The maximum connection is 10 sets of indicator.
z When the Host computer has the built-in terminal resist, it is not necessary to have
the external one.
z On the last set of indicator, the TRM & RDB can be connected depends on the
situation.
z When the host computer has no single (SG), it is acceptable to disconnect that
part.
Host computer
Host computer
