Exmark Lazer Z Series User Manual

Operation
g225819
Figure24
60and72inchModels
(Sixlocations-threeonleft,threeonright)
1.Tie-downlocation
g238192
Figure25
96inchModel
(Fourlocations-twoonleft,twoonright)
1.Fronttie-downlocation
2.Reartie-downlocation(leftsidepanelandrearbumper
removedforclarity)
•On96inchdecks,raiseandlocktheouterwing
decks(seeRaisingandLockingtheOuter
WingDecks–96InchDeckOnlysection.
•Secureatrailertothetowingvehiclewithsafety
chains.
WARNING
Drivingonthestreetorroadwaywithoutturn
signals,lights,reectivemarkings,oraslow
movingvehicleemblemisdangerousandcan
leadtoaccidentscausingpersonalinjury.
Donotdrivemachineonapublicstreetor
roadway.
LoadingtheMachine
Useextremecautionwhenloadingorunloading
machinesontoatraileroratruck.Useafull-width
rampthatiswiderthanthemachineforthis
procedure.Backuprampsanddriveforwarddown
ramps(Figure26).
g028043
Figure26
1.Backupramps
2.Driveforwarddown
ramps
Important:Donotusenarrowindividualramps
foreachsideofthemachine.
Ensuretherampislongenoughsothattheanglewith
thegrounddoesnotexceed15degrees(Figure27).
Onatground,thisrequiresaramptobeatleastfour
times(4X)aslongastheheightofthetrailerortruck
bedtotheground.Asteeperanglemaycausemower
componentstogetcaughtastheunitmovesfromthe
ramptothetrailerortruck.Steeperanglesmayalso
causethemachinetotiporlosecontrol.Ifloadingon
ornearaslope,positionthetrailerortrucksothatit
isonthedownsideoftheslopeandtherampextends
uptheslope.Thiswillminimizetherampangle.
37

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
