Exmark Lazer Z Series User Manual

Maintenance
LubricateGreaseFittings
Note:Seechartforserviceintervals.
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Lubricatettingswithonetotwopumpsof
NLGIgrade#2multi-purposegungrease.
Refertothefollowingchartforttinglocations
andlubricationschedule.
60and72inchModels
LubricationChart
Fitting
Locations
Initial
Pumps
Numberof
Places
Service
Interval
1.Deck
drivePTO
1
3
50hrs
2.Deck
idlerpivot
11
Every400
hrsor
Yearly
3.Caster
wheel
bearings
*0
2
*Yearly
4.Caster
pivots
*0
2
Every400
hrsor
Yearly
96inchModel
LubricationChart
Fitting
Locations
Initial
Pumps
Numberof
Places
Service
Interval
1.Deck
drivePTO
1
3
50hrs
2.Deck
idlerpivot
1
3Every400
hrsor
Yearly
3.Caster
wheel
bearings
*04
*Yearly
4.Caster
pivots
*05Every400
hrsor
Yearly
*Seestep3forspeciallubricationinstructionson
thefrontcasterpivotsandtheLubricateCaster
WheelHubssectionforspeciallubrication
instructionsonthefrontcasterswheelhubs.
3.Lubricatefrontcasterpivotsonceayear.Remove
hexplugandcap.Threadgreasezerkinholeand
pumpwithgreaseuntilitoozesoutaroundtop
bearing.Removegreasezerkandthreadplugback
in.Placecapbackon.
CheckWheelLugNuts
ServiceInterval:Aftertherst100hours
49

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
