Exmark Lazer Z Series User Manual

Maintenance
g231764
Figure32
1.Fillpluganddipstick
7.Ifthelubricantlevelislow,addenoughlubricant
untilthelevelisbetweenthemarksonthe
dipstick.
Important:Donotoverllthegearbox;
overllingthegearboxmaydamageit.
CheckHydraulicFluidLevel
ServiceInterval:Beforeeachuseordaily
1.Positionthemachineandmowerdeckonalevel
surface.
2.Stopengineandwaitforallmovingpartstostop.
Engageparkingbrake.
3.Raisethedecktoextendtheliftcylinders,shutoff
theengine,andremovethekey.
4.Raisetheseattoaccessthehydraulicuidtank.
5.Removethehydraulicllcapfromthellerneck.
6.Removethedipstickandwipeitwithacleanrag.
7.Placethedipstickintothellerneck;thenremove
itandcheckthelevelofuid.
g228816
Figure33
1.Full2.Add
Ifuidisneededaddenoughoiltoputthelevel
inbetweenthetwomarksonthedipstick.
Important:DoNotoverll.
8.Replacethedipstickandllcap;nger-tighten
only.
9.Checkallhosesandttingsforleaks.
CheckTirePressures
ServiceInterval:Every50hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Checktirepressureindrivetires.
3.Inatedrivetiresto18psi(124kPa).
4.Semi-pneumaticcastertiresdonotneedtobe
inated.
Note:DoNotaddanytypeoftirelinerorfoam
llmaterialtothetires.Excessiveloadscreatedby
foamlledtiresmaycausefailurestothehydrodrive
system,frame,andothercomponents.Foamlling
tireswillvoidthewarranty.
CheckConditionOfBelts
ServiceInterval:Every50hours
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Removeleftandrightbeltshieldsondeckandlift
upoorpantoinspectbelts.
48

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
