Operation

g237956

Figure5

Modelwith96InchDeck

1.RolloverProtection

System(ROPS)

7.Centerdeckheightofcut

2.EngineControls(right

console)

8.Wingdeckheightofcut

3.Seatbelt9.Leftwingdeck

4.Motioncontrollevers

10.Step

5.Fuelcap(bothsides)

11.Rightwingdeck

6.Parkingbrake

Operation

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

Controls

MotionControlLevers

Themotioncontrolleverslocatedoneachsideof

theconsolecontroltheforwardandreversemotion

ofthemachine.

Movingtheleversforwardorbackwardturns

thewheelonthesamesideforwardorreverse

respectively.Wheelspeedisproportionaltothe

amounttheleverismoved.

Movingtheleversoutwardfromthecenterposition

intotheT-slotlocksthemintheneutralposition

(Figure6).

Note:Whenthemotioncontrolleversareinthe

neutralposition,aLCDindicatordisplaysonthe

messagedisplay.

Other manuals for Exmark Lazer Z Series

Questions and Answers:

Need help?

Do you have a question about the Exmark Lazer Z Series and is the answer not in the manual?

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
