Exmark Lazer Z Series User Manual

Contents
Introduction...........................................................3
Safety.....................................................................5
SafetyAlertSymbol.........................................5
SafeOperatingPractices..................................5
SafetyandInstructionalDecals......................11
Specications........................................................20
Systems..........................................................20
Dimensions....................................................23
TorqueRequirements.....................................24
ProductOverview.................................................24
Operation..............................................................25
Controls.........................................................25
Pre-Start.........................................................29
OperatingInstructions...................................29
Transporting..................................................36
Maintenance..........................................................39
RecommendedMaintenanceSchedule(s)............39
PeriodicMaintenance........................................40
CheckEngineOilLevel..................................40
CheckBatteryCharge.....................................40
CheckMowerBlades......................................42
CheckSafetyInterlockSystem........................44
CheckRolloverProtectionsSystems(Roll
Bar)Knobs.................................................47
CheckSeatBelt...............................................47
CheckforLooseHardware.............................47
ServiceAirCleaner.........................................47
CheckDeckGearboxOil................................47
CheckHydraulicFluidLevel...........................48
CheckTirePressures......................................48
CheckConditionOfBelts...............................48
LubricateGreaseFittings................................49
CheckWheelLugNuts...................................49
DrainFuelFilter/WaterSeparator...................50
ChangeFuelFilter/WaterSeparator................51
ChangeDeckGearboxOil..............................52
ChangeEngineOilandFilter..........................52
ChangeHydraulicSystemFilterand
Fluid..........................................................52
CheckEngineCoolantLevel...........................54
ChangeEngineCoolant..................................54
ThreadLockingAdhesives..............................55
MobilHTSGrease(OrFood-Grade
Anti-seize)..................................................55
Copper-BasedAnti-seize...............................55
DielectricGrease............................................56
Adjustments......................................................56
DeckLeveling–60and72InchModels............56
DeckLeveling–96InchModels.......................58
DeckBeltTension..........................................61
ParkingBrakeAdjustment..............................61
MotionControlLinkageAdjustment..............62
MotionControlDamperAdjustment..............63
CasterPivotBearingsPre-Load
Adjustment................................................63
Cleaning............................................................64
CleanEngineandExhaustSystem
Area...........................................................64
CleantheRadiator..........................................64
CleanDebrisFromMachine...........................65
CleanGrassBuild-UpUnderDeck.................65
InspectEngineValveClearance......................65
WasteDisposal...............................................65
Troubleshooting....................................................66
Schematics............................................................68
4

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
