Exmark Lazer Z Series User Manual

Operation
g238020
Figure22
Undersideof96InchDeck
1.Anti-scalproller
AdjustingtheSideBumpers
(RearDischargeUnitsOnly)
Mountthesidebumpersinthetopholeswhen
operatinginheightofcutshigherthan21/2inches
(64mm)andinthecenterholeswhenoperatingin
heightofcutslowerthan21/2inches(64mm).
Note:Whenbumpersbecomeworn,switchthe
bumperstotheoppositesidesofthemower,ipping
themover.Thisallowsthebumperstobeusedlonger
beforereplacingthem.
1.Stopthemachineandmovethemotioncontrol
leversoutwardtotheneutrallockedposition.
2.DisengagethePTO.
3.Engagetheparkbrake.
4.Stoptheengine,removethekeyandwaitforall
movingpartstostop.
5.Raisethedecktothetransportposition.
6.Removetheboltsandnutsfromeachbumper.
g238205
Figure23
1.Bolt3.Nut
2.Bumper
7.Moveeachbumpertothedesiredpositionand
securethemwiththeboltsandnuts.
Note:Onlyusethetoporcentersetsofholesto
adjustthebumpers.Thebottomholesareused
whenswitchingsides,atwhichtimetheybecome
thetopholesontheothersideofthemower.
Transporting
TransportingtheMachine
Useaheavy-dutytrailerortrucktotransportthe
machine.Ensurethatthetrailerortruckhasall
necessarylightingandmarkingasrequiredbylaw.
Thoroughlyreadallofthesafetyinstructions.
Knowingthisinformationcouldhelpyou,your
family,pets,orbystandersavoidinjury.
Totransportthemachine:
•Lockthebrakeandblockthewheels.
•Securelyfastenthemachinetothetrailerortruck
withstraps,chains,cable,orropes.Onlyusethe
designatedtie-downlocationsonthemower(see
Figure24andFigure25).Usetheselocationseven
whentransportingthemowerwithanattached
accessory.Usingnon-designatedlocationsmay
causedamagetothemowerand/orattachment.
36

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
