Exmark Lazer Z Series User Manual

Maintenance
5.Loosenlocknutsfromtheballjointsateachend
ofthepumpcontrollinkage(Figure53).
g228557
Figure53
Right-HandSideofUnit
1.Turnheretoadjust
2.Loosenhere(right-hand
thread)
6.Startengine.Brakemustbeengagedand
motioncontrolleversouttostartengine.
Operatordoesnothavetobeintheseat
becauseofthejumperwirebeingused.Run
engineatfullthrottleandreleasebrake.
Note:Themotioncontrolleverneedstobein
neutralwhilemakinganynecessaryadjustments.
Theleftrodassemblycontrolstheleftwheeland
therightrodassemblycontrolstherightwheel.
7.Bringthemotioncontrolleverintotheneutral
position.AdjustRHpumpcontrolrodlength
byrotatingthedoublenutsontherodinthe
appropriatedirectionuntilthewheelsslightly
creepinreverse.Movethemotioncontrollever
tothereversepositionandwhileapplyingslight
pressuretotheleverallowthereverseindicator
springtobringtheleversbacktoneutral.The
wheelmuststopturningorslightlycreepin
reverse.Whenadjustmentiscomplete,tighten
locknutsontoballjoints.RepeatforLHmotion
controllever.
8.Shutoffunit.Removejumperwirefromwire
harnessconnectorandplugconnectorintoseat
switch.
MotionControlDamper
Adjustment
Thetopdampermountingboltcanbeadjustedto
obtainamoredesiredmotioncontrolleverresistance.
SeeFigure54formountingoptions.
g008620
Figure54
RHMotionControlShown
1.Torquenylocnutto200in-lb(16.7ft-lb).Boltmust
protrudepastendofnylocnutaftertorque.AT-40T orx
bitwillbenecessarytoholdthestudfromturning.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
CasterPivotBearings
Pre-LoadAdjustment
Removedustcapfromcasterandtightennylocnut
untilwashersareatandbackoff1/4ofaturn
toproperlysetthepre-loadonthebearings.If
disassembled,makesurethespringdiscwashersare
reinstalledasshowninFigure55.
63

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
