Exmark Lazer Z Series User Manual

Maintenance
g240665
Figure51
RHWingDeckShown
1.Rearhangermountingnuts
2.Rearheightadjustmenthardwarelocation
3.Singlepointrearadjustment
4.Fronthangermountingnuts
5.Frontheightadjustmenthardwarelocation
•Ifthedeckistoolow,tightenthefrontheight
adjustmentbolt(item5,Figure51)byrotating
thebottomnutclockwise.
•Ifthedeckistoohigh,loosenthefrontheight
adjustmentbolt(item5,Figure51)byrotating
thebottomnutcounterclockwise.Finetuned
therearadjustersasrequired.
Adjusttherearwheelheight(item2,Figure51)
sothattherearwheellightlytouchestheground
withminimalpressure.
4.Measurethebackofthewingblades.Ifeither
haslessthan1/16inch(1.5mm)rake,raisethe
backofthedeckbytighteningtheLHandRH
rearadjustments(item3,Figure51)untilall
fourbladeshaveaminimumof1/16inchrake
(1.5mm).Readjustthewingrearwheelssothey
lightlytouchthegroundwithminimalpressure.
Tightenallfourrearhangermountpoints(item
1,Figure51).
5.Retightenthefrontandrearheightofcuthanger
jamnuts.
DeckBeltTension
Self-tensioning-Noadjustmentnecessary.
ParkingBrakeAdjustment
ServiceInterval:Aftertherst100hours
Every400hoursthereafter
Checktomakesurebrakeisadjustedproperly.This
proceduremustbefollowedaftertherst100hours
orwhenabrakecomponenthasbeenremovedor
replaced.
CAUTION
Raisingthemowerdeckforserviceor
maintenancerelyingsolelyonmechanical
orhydraulicjackscouldbedangerous.The
mechanicalorhydraulicjacksmaynotbeenough
supportormaymalfunctionallowingtheunitto
fall,whichcouldcauseinjury.
DoNotrelysolelyonmechanicalorhydraulic
jacksforsupport.Useadequatejackstandsor
equivalentsupport.
1.Drivethemachineontoalevelsurface.
2.Disengagethebladecontrolswitch(PTO),move
themotioncontrolleverstotheneutrallocked
positionandengagetheparkingbrake(leverisin
the“up”position).
3.Stoptheengine,waitforallmovingpartstostop,
andremovethekey.
4.Raisethebackofthemachineupandsupportthe
machinewithjackstands.
5.Removethereartiresfromthemachine.
6.Removeanydebrisfromthebrakearea.
7.Rotatethedrivewheelreleasehandletothe
“released”position.RefertotheDriveWheel
ReleaseValvessectioninOperation.
8.Ifthelinkassemblyisattached(seeFigure52)
•inthefrontposition,thelength=8.63inches
(21.9cm).
•intherearposition,thelength=9.15inches
(23.2cm).
9.Thelengthofthespringshouldmeasure31/4
inches(8.3cm).
10.Oncethespringlengthisachieved,checktosee
ifthereisavisiblegapbetweenthetrunionand
theshoulder.
61

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
