Exmark Lazer Z Series User Manual

Maintenance
g228555
Figure52
1.Frontlocation
5.Spring
2.Rearlocation6.Linkassembly
3.31/4inches(8.3cm)
7.Length
4.Gap
11.Disengagetheparkbrake,thelevershouldbein
thedownposition.Turnthewheelhubbyhand
inbothdirectionsrelativetothecaliper;thewheel
hubshouldmovefreely.
12.Ifagapisneededorthewheelhubdoesnot
movefreely:
A.Disengagetheparkbrake.
B.Disconnectandne-tunetherearlinkage
assembly:
•Shortenthelinktocreateagap.
•Lengthenthelinktoallowwheelhub
movement.
C.Reconnecttherearlinkageassembly.
13.Engagetheparkingbrakeandcheckthegap.
14.Repeatsteps11through14untilavisiblegapis
achievedandthewheelhubrotatesfreely.Repeat
forthebrakeontherightside.
Note:Thebrakeshouldfullydisengagewhen
thebrakeisinthe“released”position.
15.Rotatethedrivewheelreleasehandletothe
“operating”position.RefertotheDriveWheel
ReleaseValvessectioninOperation.
16.Installthereartiresandtorquelugnutsto85-105
ft-lb(115-142N-m).
17.Removejackstands.
MotionControlLinkage
Adjustment
WARNING
Enginemustberunninganddrivewheelsmust
beturningsomotioncontroladjustmentcanbe
performed.Contactwithmovingpartsorhot
surfacesmaycausepersonalinjury.
Keepngers,hands,andclothingclearof
rotatingcomponentsandhotsurfaces.
CAUTION
Raisingthemowerdeckforserviceor
maintenancerelyingsolelyonmechanical
orhydraulicjackscouldbedangerous.The
mechanicalorhydraulicjacksmaynotbeenough
supportormaymalfunctionallowingtheunitto
fall,whichcouldcauseinjury.
DoNotrelysolelyonmechanicalorhydraulic
jacksforsupport.Useadequatejackstandsor
equivalentsupport.
1.Thisadjustmentmustbemadewiththedrive
wheelsturning.Firstraisetherearofmachine
upandsupportwithjackstands(orequivalent
support)justhighenoughtoallowthedrive
wheelstorotatefreely.
2.Unhookseatlatchandtiltseatforward.
3.Removetheelectricalconnectionfromtheseat
safetyswitch,locateddirectlytotheleftoftheseat
switchassemblybesidethehydraulicoilreservoir.
Temporarilyinstallajumperwireacrossthe
terminalsintheconnectorofthemainwiring
harness.
4.Runtheunitatleast5minuteswiththedrive
leversatfullforwardspeedtobringhydraulic
systemoiluptooperatingtemperature.
62

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
