Maintenance
C.Removethereservoircapanddipstickfrom
theuidtank.
D.Add8qt(7.6L)ofoilinthereservoir.
Note:Thereservoirwillbeoverfullatthis
pointthelevelwillquicklygodownoncethe
machineisstartedandcoolingloopoillls
thetransmissioncase.
Important:Exmarkwillnotassume
responsibilityfordamagecausedbyimproper
substitutions.
7.Raisetherearofmachineupandsupportwith
jackstands(orequivalentsupport)justhigh
enoughtoallowdrivewheelstoturnfreely.
8.Allowtheenginetorunaboutoneminuteand
thenshutitoff.
9.Starttheengineandcheckforoilleaks.Movethe
speedcontrolleverstothefullspeedandrunfor
severalminutes.Shutdownmachineandrecheck
uidlevel.
10.Checkthelevelofthehydraulicuid;referto
CheckHydraulicFluidLevelsection.
Addenoughoiltoputthelevelbetweenthetwo
marksonthedipstick.itmaytake4-5qt(3.8-4.7
L)dependinghowmuchoilstayedinthecooling
loopwhiledraining.
11.Replacethedipstickandreinstallthecap.
CheckEngineCoolantLevel
ServiceInterval:Beforeeachuseordaily
Note:Iftheenginecoolantlevelisbelowthe
indicatorlineontheoverowbottlewhenthe
engineiscold,thecoolanttemperaturegaugemay
notregistercorrectlyduringoperationand/or
thewarningbuzzermaynotsoundiftheengine
overheats.
1.Positionthemoweronaatsurface.
2.Stopengineandwaitforallmovingpartstostop.
3.Checkwithenginecold.
4.Openthehoodandcheckthecoolantlevelinthe
expansiontankontherightsideofthemachine.
Thecoolantlevelshouldbebetweenthemarks
ontheoverowbottle.
g022120
Figure40
1.Expansiontank
5.Ifthecoolantlevelislow ,removethecapto
theoverowbottleandlltotheindicatorline.
Machinesshouldonlybelleda50/50mixof
waterandethyleneglycol.
Note:TheuseofHavoline
®
XtendedLife
coolantisrecommended.Havoline
®
canbe
identiedbyitsorangecolor.
WARNING
Enginecoolantishotandpressurizedand
radiatorandsurroundingpartsarehot.Sprayor
steamfromhot,pressurizedliquidintheengine
coolingsystemandtouchingahotradiatormay
causesevereburns.
Allowtheenginetocoolcompletelybefore
removingtheradiatorcaporservicingany
componentofthecoolingsystem.
CAUTION
Enginecoolantistoxic.Swallowingcoolantcan
causepoisoning.
•DoNotswallow.
•Keepoutofreachofchildrenandpets.
ChangeEngineCoolant
ServiceInterval:Every2,000hours/Every2
years(whichevercomes
rst)
1.Positionthemoweronaatsurface.
2.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
3.Tilthoodforwardtogainaccesstothecooling
area.
54

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
