Maintenance
Every400hours—Change
thehydrauliclterand
uidifusingMobiluid
™
424.
Every800hours—Change
thehydrauliclterand
uidifusingExmarkRuby
Tran
™
Fluid.
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Raiseseat.
3.Therearefourdrainplugsthatneedtobe
removedtodoacompleteuidchange.Place
apanundereachdrainplugfromthefollowing
components:hydraulicreservoir,transmission
case,andtheleftandrightwheelmotors(see
Figure38).
g231945
Figure38
Undersideofthemachine
1.Rearframe
4.Transmissioncasedrain
plug
2.LHwheelmotordrain
plug
5.RHwheelmotordrain
plug
3.Hydraulicreservoirdrain
plug
6.Filter
4.Unscrewtheltertoremoveandallowuidto
drainfromreservoir.
Important:Beforereinstallingnew
lter,applyathincoatofExmarkRuby
TransmissionFluidonthesurfaceofthe
rubberseal.
Installanewlterandturnthelterclockwise
untiltherubbersealcontactsthelteradapter,
thentightenthelteranadditional2/3to3/4
turn.
5.Reinstallallfourplugs.Thewheelmotordrain
plugsaremagnetic;wipecleanbeforereinstalling.
6.Removethellportplugonthetopofeach
wheelmotor.
g235097
Figure39
1.Fillport
A.Filleachmotorwithapproximately1.5qt(1.4
L)ExmarkRubyTransmissionFluid.
ExmarkRubyTransmissionFluidis
recommended.Refertothechartforan
acceptablealternative:
HydroOil
ChangeInterval
ExmarkRubyTranFluid.Afterrst200hours
*Every800hours
thereafter
Mobiluid424Afterrst200hours
*Every400hours
thereafter
*Mayneedmoreoftenundersevere
conditions.
B.Replacetheplugs.
53

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
