Exmark Lazer Z Series User Manual

Maintenance
CheckEngineStartingCircuitChart
Note:IntheCheckEngineStartingCircuitChart,thestateofsystemitemthatisboldisbeingchecked
ineachscenario.
System
ParkingBrake
PTO
(Blades)
MotionControlLeversOperatorOutcome
EngagedDisengaged
Bothleversmovedin,oreither
rightorleftlevermovedin
Operator
inseat
Startermust
notcrank
Disengaged
Disengaged
Bothleversout(neutrallock)
Operator
inseat
Startermust
notcrank
Stateof
System
CheckShutdownCircuitChart
Note:Thestateofsystemitem(s)thatisboldisbeingcheckedineachscenario.
System
EngineParking
Brake
PTO(Blades)
MotionControl
Levers
OperatorOutcome
Runningidle
(1/3throttleor
efcientmode)
DisengagedDisengaged
Bothleversmoved
out(neutrallock)
orbothlevers
movedin
Raiseoff
ofseat(but
don’tget
off)
Enginemust
beginshutdown
within1second
State
of
System
45

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
